All relevant charging cable and plug types

Here, you will find an overview of all relevant charging cable and plug types for electric mobility. Using the right combination of cables for your EV will make your EV ready for use in no time.

The Mode 2 charging cable is available in different versions. Often the Mode 2 charging cable for connection to an ordinary domestic socket is supplied by the car manufacturer. So if necessary drivers can charge electric cars from a domestic socket in an emergency. Communication between vehicle and charging port is provided via a box connected between the vehicle plug and connector plug (ICCB In-Cable Control Box). The more advanced version is a Mode 2 charging cable with a connector for different CEE industrial sockets, such as NRGkick. This allows you to fully charge your electric car, depending on the CEE plug type, in a short time at up to 22 kW.

The mode 3 charging cable is a connector cable between the charging station and the electric car. In Europe, the type 2 plug has been set as the standard. To allow electric cars to be charged using type 1 and type 2 plugs, charging stations are usually equipped with a type 2 socket. To charge your electric car, you require either a mode 3 charging cable from type 2 to type 2 (e.g. for the Renault ZOE) or a mode 3 charging cable from type 2 to type 1 (e.g. for the Nissan Leaf).

The type 1 plug is a single-phase plug which allows for charging power levels of up to 7.4 kW (230 V, 32 A). The standard is mainly used in car models from the Asian region, and is rare in Europe, which is why there are very few public type 1 charging stations.

The triple-phase plug’s main area of distribution is Europe, and is considered to be the standard model. In private spaces, charging power levels of up to 22 kW are common, while charging power levels of up to 43 kW (400 V, 63 A, AC) can be used at public charging stations. Most public charging stations are equipped with a type 2 socket. All mode 3 charging cables can be used with this, and electric cars can be charged with both type 1 and type 2 plugs. All mode 3 cables on the sides of charging stations have so-called Mennekes plugs (type 2).

The CCS plug is an enhanced version of the type 2 plug, with two additional power contacts for the purposes of quick charging, and supports AC and DC charging power levels (alternating and direct current charging power levels) of up to 170 kW. In practice, the value is usually around 50 kW.

This quick charging system was developed in Japan, and allows for charging capacities up to 50 kW at the appropriate public charging stations. The following manufacturers offer electric cars which are compatible with the CHAdeMO plug: BD Otomotive, Citroën, Honda, Kia, Mazda, Mitsubishi, Nissan, Peugeot, Subaru, Tesla (with adaptor) and Toyota.
