Charging & Energy Management

Would you like to charge 10, 20, 50 or even more electric vehicles all at the same time?

One system, full flexibility

The Mobility House‘s Charging and Energy Management system charges your electric vehicles reliably, intelligently and cost-effectively. With just one system you can manage loads and bill the cost of charging processes - completely independently of the charging station and vehicle manufacturer. Because your system can grow with your needs, you have the flexibility to deal with whatever the future brings.

How you benefit

 Icon - Charge several EVs simultaneously

Maximize utilization

At power-constrained sites, our Charging & Energy Management maximizes the number of vehicles that can be charged simultaneously.

 Icon - reduce load peaks

Reduce costs

The system prevents expensive peak loads and grid connection costs, in turn reducing installation and operating costs.

 Icon - data security

Secure & local

Our solution works directly on site. This guarantees maximum stability while charging and data security.

 Icon - modular system

Modular

You can add new modules at any time: a billing service, for example.

 Icon - scalability

Scalable

Is your fleet growing? Simply add more charging stations to your system!

 Icon - independence

Remain independent

Don’t get locked in with a single charging station or vehicle manufacturer.

How the Charging & Energy Management works:

That's what our Charging and Energy Management can do for you



Load Management variant: Basic



Load Management variant: Dynamic



ensures that all electric vehicles within the maximum possible power connection line are reliably charged



✔︎



✔︎

takes into account the current building load and makes optimal use of the grid connection



✔︎

recognizes the actual charging capacity, incl. asymmetrical phase load through one- and two-phase EVs and uses the total output available for charging in the best possible way

✔︎  ✔︎

can prioritize individual charging stations or RFID cards

✔︎ ✔︎

offers interfaces with other systems (e.g. billing software, SAP, has.to.be, network operators)

✔︎ ✔︎

sends alert messages in case of charging station failures

✔︎ ✔︎

continues charging EVs via the local control element, even during loss of internet connection

✔︎ ✔︎

transfers data via SSL/TLS encryption

✔︎ ✔︎

visualises charging processes, statistics, malfunctions in the TMH backend

✔︎ ✔︎

can be scaled as desired and is independent of hardware

✔︎ ✔︎

Pricing

Load Management Basic

Load management Basic

One-off Hardware- & Setup- Costs: 712.81 EUR*

(inkl. Smart Charging Controller & Set-up pro location)


Subscription per charging point: 4.74 EUR*

(monthly costs)

*Prices incl. 19% VAT

Load Management Dynamic

Load Management Dynamic

One-off Hardware- & Setup- Costs: 1,069.81 EUR*

(inkl. Smart Charging Controller, Electric Meter & Set-up pro location)

Subscription per charging point: 7.14 EUR*

(monthly costs)

*Prices incl. 19% VAT

We help you design, implement and operate the charging solution that‘s right for you

 Charging- and Energy Management Process

01 Concept

Together we determine your charging requirements and design an intelligent charging solution tailored to your needs.

02 Implementation

We support in the entire process of setting up your charging infrastructure. We test the hardware, as well as configuring all of its smart functions.

03 Operation

Maintain full controll with no effort and expand your system on demand. Our service team is there for you at all times.

The Smart Charging Controller as a Local Control Element

The Smart Charging Controller constitutes the central element of charging management. It controls all charging processes and simultaneously serves as a connection element to the The Mobility House (TMH) backend.


TMH Smart Charging Controller
Flexibility and speed

  • Quick reaction time and no impairment with latency times
  • The Mobility House (THM) controller will also be able to link with other relevant assets (PV, memory, etc.) in the future
Stability

  • By way of local control, functionality is also guaranteed during internet downtime
  • Low data volume via local optimization and communication with charge points
Data security

  • Secure transfer of data via SSL/TLS encryption
  • Security is independent of telecommunications provider

Technical data of the Smart Charging Controller

Housing dimensions (HxWxD)



96 x 22,5 x 110,5 mm

Housing type



DIN rail housing (EN 50022)

Power supply

min. 10,7 V - max. 28,8 V



Operating temperature

-40 °C to +55 °C



Interfaces

2 x USB 2.0 A (each chargeable with 500mA)

1 x Micro-USB

1 x Micro HDMI

1 x RJ45 (Ethernet)

10/100 Mbit/s

Optical indicator

3 status LEDs (bi-color)

Compatible Charging Stations

ICU Wallbox Eve Mini 904460002B (3,7kW, inkl. 5m Ladekabel Typ2, RFID, SIM oder UTP)
ICU charging station Eve Mini 904460002B (3,7kW, incl. 5m cable type2, RFID, SIM or UTP)
€1,099.00

incl. 19% tax & shipping costs in DE & AT

  • RFID
  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: On request
ICU Wallbox Eve Mini 904460003 (3,7kW, Steckdose Typ2, Plug & Charge, SIM oder UTP) | The Mobility House
ICU charging station Eve Mini 904460003 (3,7 kW, socket type2, Plug & Charge, SIM or UTP)
€1,049.00

incl. 19% tax & shipping costs in DE & AT

  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: On request
ICU Wallbox Eve Mini 904460004 (3,7kW, Steckdose Typ2, RFID, SIM oder UTP) | The Mobility House
ICU charging station Eve Mini 904460004 (3,7 kW, socket type 2, RFID, SIM or UTP)
€1,099.00

incl. 19% tax & shipping costs in DE & AT

  • RFID
  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: On request
ICU Wallbox Eve Mini 904460001B (3,7kW, inkl. 5m Ladekabel Typ2, Plug & Charge, SIM oder UTP) | The Mobility House
ICU charging station Eve Mini 904460001B (3,7 kW, incl. 5m cable type2, Plug & Charge, SIM or UTP)
€1,049.00

incl. 19% tax & shipping costs in DE & AT

  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: On request
ICU Wallbox001-009-000014 Eve Mini 904460031B (22kW, inkl. 5m Ladekabel Typ2, Plug & Charge, SIM oder UTP) | The Mobility House
ICU charging station Eve Mini 904460031B (22 kW, incl. 5m cable type2, Plug & Charge, SIM or UTP)
€1,199.00

incl. 19% tax & shipping costs in DE & AT

  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: 2-3 weeks, no express possible
ICU Wallbox Eve Mini 904460034 (22kW, Steckdose Typ2, RFID, SIM oder UTP) | The Mobility House
ICU charging station Eve Mini 904460034 (22 kW, socket type 2, RFID, SIM or UTP)
€1,249.00

incl. 19% tax & shipping costs in DE & AT

  • RFID
  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: 2-3 weeks, no express possible
ICU Wallbox Eve Mini 904460033 (22kW, Steckdose Typ2, Plug & Charge, SIM oder UTP) | The Mobility House
ICU charging station Eve Mini 904460033 (22 kW, socket type 2, Plug & Charge, SIM or UTP)
€1,199.00

incl. 19% tax & shipping costs in DE & AT

  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: 2-3 weeks, no express possible
ICU Wallbox Eve Mini 904460032B (22kW, inkl. 5m Ladekabel Typ2, RFID, SIM oder UTP) | The Mobility House
ICU charging station Eve Mini 904460032B (22kW, incl. 5m cable type2, RFID, SIM or UTP)
€1,249.00

incl. 19% tax & shipping costs in DE & AT

  • RFID
  • Billing
  • Load Management
  • OCPP
  • SIM
  • LAN
Lieferzeit: 2-3 weeks, no express possible
 The best way to charge and manage your fleet
 Effortlessly prioritise you charge points
Track your energy consumption

You would like an individual consultation? We gladly support you.
